Hybrid Inverter

Abundance Energy Hub

5kW to 25kW three-phase hybrid inverter with up to 4 MPPTs and built-in battery management. Developed in partnership with Sigenergy — battery-ready from day one, IP66 rated, with Type II DC/AC surge protection and optional AFCI on supported models.

10-Year Standard Warranty
Abundance Pro
98.3%
Maximum Efficiency
5–25kW
Power Range
30kW
Peak Backup Power
6pcs
Max SigenStor Modules

Why Sigen Hybrid

Developed in partnership with Sigenergy — the intelligent hybrid inverter that manages solar, battery, and grid as one seamless ecosystem.

Battery-Ready from Day One

True hybrid architecture with integrated battery management. Add up to 6 SigenStor modules whenever you're ready — no additional inverter or retrofit required. Up to 30kW peak backup power keeps your home running during outages.

Up to 4 Independent MPPTs

Scale from 2 to 4 MPP trackers as your system grows. Each tracker independently optimises a string of Eclipse panels, maximising harvest across multiple roof orientations and shading conditions.

IP66 Tropical-Grade Protection

IP66 ingress protection handles Singapore's heaviest downpours and salt-air humidity. Type II surge protection on both DC and AC, anti-islanding, insulation and residual-current monitoring — plus optional AFCI on supported models.

Technical Specifications

DC Input

Maximum Input Voltage
1,100 V
Nominal DC Input Voltage
600 V
Maximum Inverter Efficiency
98.1–98.3%
Start-up Voltage
180 V
MPPT Voltage Range
160–1,000 V
Number of MPP Trackers
2 (5–8kW) / 3 (10–15kW) / 4 (17–25kW)
PV Strings per MPPT
1
Max Input Current per MPPT
16 A
Max Short-Circuit Current per MPPT
20 A
Max PV Power
8,000–40,000 W
European Weighted Efficiency
96.1% – 98.0% (by model)

AC Output (On-Grid)

Nominal Output Power
5,000–25,000 W
Max Output Apparent Power
5,500–27,500 VA
AC Output Voltage (nominal)
3/N/PE, 380/400 V
Power Factor
0.8 leading – 0.8 lagging
Nominal Grid Frequency
50/60 Hz
Total Current Harmonic Distortion
THDi < 2%
Nominal Output Current
7.6–38.0 A
Max Output Current
8.4–41.8 A

Battery Storage

Compatible Battery Module
SigenStor BAT 5.0 / 8.0
Modules per Controller
1–6
Battery Module Voltage Range
600–900 V

Backup Power

Peak Output Power (10s)
7,500–30,000 W
Nominal Backup Voltage
380/400 V (Three-Phase)
Grid Connection Type
Three-Phase (3/N/PE)

Physical

Dimensions (W × H × D)
700 × 300 × 283 mm
Weight
36 kg
Protection Rating
IP66
Safety Compliance
IEC/EN 62109-1, IEC/EN 62109-2, IEC/EN 61000-6-1, IEC/EN 61000-6-2
Operating Temperature
-30°C to +60°C
Cooling Method
Smart Air Cooling
Communication
WLAN / Fast Ethernet / RS485 / Sigen CommMod (4G/3G/2G)
Installation Method
Wall-Mounted
Max Operating Altitude
4,000 m
Relative Humidity
0%–95%
Storage Temperature
-40°C to +70°C

Protection and Safety

Arc Fault Circuit Interrupter (AFCI)
Yes (Optional)
Surge Protection
DC Type II / AC Type II
DC Reverse Polarity Protection
Yes
Insulation Monitoring
Yes
Residual Current Monitoring
Yes
AC Overcurrent / Overvoltage / Short-Circuit
Yes
Anti-Islanding Protection
Yes

Part of Abundance Pro

The Sigen Hybrid Inverter is the heart of Sunollo's most advanced home energy system.

Abundance Pro

The complete ecosystem: Eclipse panels, SunMax optimizers, Sigen Hybrid inverter, SigenStor battery and EV options. From $16,000.

Explore Abundance Pro →

Eclipse Solar Panels

540W all-black N-Type ABC panels with 24.4% efficiency. The power source feeding your Abundance Energy Hub.

View Panel Specs →

SunMax Optimizers

Sungrow SP600S panel-level optimization with Shade-Proof technology and module-level diagnostics.

View Optimizer Specs →
